Allen Bradley 2711R-T7T PanelView 800 HMI Terminal
- Product Details
- FAQs
- Related
- Contact Us
- Packing & Delivery
- Product Ratings
Product Introduction
The Allen Bradley 2711R-T7T PanelView 800 HMI Terminal is a compact and efficient human-machine interface designed for industrial automation, machine control, and process monitoring applications. Equipped with a responsive touchscreen and a 7-inch color TFT display, this terminal provides operators with clear visualization of machine status, alarms, diagnostics, and operational information in real time.
The PanelView 800 series is developed for small and medium-sized automation systems that require reliable HMI performance, flexible communication options, and simple integration with industrial control equipment. Its 800 × 480 WVGA resolution delivers sharp graphics and clear text visibility, improving operator interaction and process monitoring efficiency.
This model supports Ethernet communication along with RS-232/422/485 serial connectivity, enabling seamless integration with PLCs, drives, and industrial controllers. With 256 MB internal storage and 256 MB RAM, the terminal delivers stable and dependable performance for industrial visualization tasks. Powered by a 24 VDC input supply, the unit is suitable for packaging equipment, OEM machinery, conveyor systems, and general manufacturing automation applications requiring compact touchscreen HMI functionality.
Product Specifications
| Parameter | Specification |
|---|---|
| Model | 2711R-T7T |
| Series | PanelView 800 |
| Display Size | 7 Inch |
| Display Type | Color TFT Display |
| Resolution | 800 × 480 WVGA |
| Input Method | Touchscreen |
| Communication Port | Ethernet |
| Serial Communication | RS-232/422/485 |
| Internal Storage | 256 MB |
| RAM Memory | 256 MB |
| Input Voltage | 24 VDC |
| Mounting Type | Panel Mount |
| Interface Type | Human Machine Interface (HMI) |
| Display Technology | TFT Color Display |
| Cooling Method | Passive Cooling |
| Application Type | Industrial Operator Terminal |
| Dimensions | 197 × 54 × 144 mm |
| Weight | 0.651 kg |
Applications
• Industrial Automation: Provides operator monitoring and machine control for automated production systems.
• Packaging Machinery: Suitable for packaging lines, filling systems, and labeling equipment requiring touchscreen operation.
• OEM Equipment: Ideal for machine builders requiring compact and reliable HMI solutions.
• Material Handling Systems: Supports conveyor monitoring and transport equipment control applications.
• Process Visualization: Displays machine status, alarms, diagnostics, and operational data clearly and efficiently.
Advantages
• Compact Touchscreen Design: Small footprint allows installation in limited control panel spaces.
• Clear WVGA Display: The 7-inch color screen delivers sharp graphics and improved readability.
• Flexible Communication Support: Ethernet and RS-232/422/485 interfaces provide broad industrial compatibility.
• Reliable Performance: 256 MB storage and RAM ensure stable operation for industrial HMI applications.
• Easy System Integration: Compatible with Allen Bradley PLC systems and industrial automation platforms.
• Efficient Industrial Operation: Designed for dependable continuous use in automation environments.
FAQ
- What type of display does this HMI terminal use?
The terminal features a 7-inch color TFT touchscreen display with an 800 × 480 WVGA resolution. - What communication interfaces are available?
The unit supports Ethernet communication along with RS-232/422/485 serial connectivity. - What power supply is required for operation?
The terminal operates using a 24 VDC input power supply. - How much memory does the device include?
It includes 256 MB internal storage and 256 MB RAM for HMI applications and process visualization. - Is the touchscreen suitable for industrial environments?
Yes, the touchscreen is designed for reliable operation in industrial automation systems. - What applications commonly use this HMI terminal?
It is commonly used in packaging systems, OEM machinery, conveyor equipment, and industrial automation applications. - Can the terminal display alarms and diagnostics?
Yes, it supports machine monitoring, diagnostics, alarms, and graphical process visualization. - How is the unit installed?
The terminal is designed for panel mounting inside industrial control cabinets and operator stations. - Does the terminal support PLC integration?
Yes, the Ethernet and serial communication interfaces support integration with industrial PLC systems. - What is the advantage of the WVGA display resolution?
The WVGA display provides improved graphical clarity, better text visibility, and enhanced operator interaction.
Related Models
| Model | Display Size | Resolution | Input Type | Features |
|---|---|---|---|---|
| 2711R-T4T | 4.3 Inch | 480 × 272 | Touchscreen | Compact HMI |
| 2711R-T7T | 7 Inch | 800 × 480 | Touchscreen | Ethernet + Serial |
| 2711R-T10T | 10 Inch | 800 × 600 | Touchscreen | Large Display |
| 2711R-K7T | 7 Inch | 800 × 480 | Keypad & Touch | Industrial HMI |
| 2711P-T7C4D9 | 6.5 Inch | 640 × 480 | Touchscreen | PanelView Plus 6 |
| 2711P-T12W22D9P | 12.1 Inch | 1280 × 800 | Touchscreen | Performance Display |
Popular Models
| Model | Display Size | Resolution | Input Type | Features |
|---|---|---|---|---|
| 2711R-T7T | 7 Inch | 800 × 480 | Touchscreen | Compact HMI Terminal |
| 2711R-T10T | 10 Inch | 800 × 600 | Touchscreen | PanelView 800 |
| 2711R-K7T | 7 Inch | 800 × 480 | Keypad & Touch | Industrial Operator Interface |
| 2711P-T7C22D9P | 6.5 Inch | 640 × 480 | Touchscreen | Windows 10 IoT Core |
| 2711P-T7C4D9 | 6.5 Inch | 640 × 480 | Touchscreen | Windows CE 6 Extended |
| 2711P-T12W22D9P | 12.1 Inch | 1280 × 800 | Touchscreen | Performance Widescreen |
