Allen Bradley 5069-AEN2TR Compact 5000 I/O EtherNet/IP Adapter
- Product Details
- FAQs
- Related
- Contact Us
- Packing & Delivery
- Product Ratings
Product Introduction
The Allen Bradley 5069-AEN2TR Compact 5000 I/O EtherNet/IP Adapter is a high-speed industrial communication module designed for Compact 5000 distributed I/O systems and CompactLogix automation platforms. It provides reliable EtherNet/IP network connectivity between controllers, field devices, and remote I/O modules, supporting efficient industrial communication in modern automation systems.
Equipped with dual 1 Gigabit Ethernet ports, the adapter supports 10/100/1000 Mbps communication speeds for fast and stable data transfer. The dual-port design allows flexible network topologies and simplified integration into industrial Ethernet architectures. This makes the module suitable for high-performance automation environments requiring real-time communication and dependable distributed control.
Operating on an 18–32 VDC power supply, the 5069-AEN2TR is engineered for industrial reliability while maintaining a compact footprint for control panel installation. Its DIN rail mounting structure simplifies cabinet integration, and the Compact 5000 architecture ensures seamless compatibility with Allen Bradley CompactLogix systems. The adapter is widely used in manufacturing, packaging, process automation, and material handling systems requiring high-speed EtherNet/IP communication.
Product Specifications
| Parameter | Specification |
|---|---|
| Model | 5069-AEN2TR |
| Series | Compact 5000 |
| Product Type | EtherNet/IP Adapter |
| Controller Compatibility | CompactLogix |
| Communication Protocol | EtherNet/IP |
| Ethernet Ports | Dual 1GB Ports |
| Communication Speed | 10/100/1000 Mbps |
| Input Voltage | 18–32 VDC |
| Current Consumption | 450 mA |
| Housing Type | Open Type |
| Mounting Type | DIN Rail Mounting |
| Application Type | Distributed I/O Communication |
| Network Architecture | Industrial Ethernet |
| Cooling Method | Passive Cooling |
| Dimensions | 136.8 × 98.1 × 123 mm |
| Weight | 0.68 kg |
Applications
• Distributed I/O Systems: Provides network communication between CompactLogix controllers and remote I/O modules.
• Industrial Automation Networks: Supports EtherNet/IP connectivity in manufacturing and process automation systems.
• Packaging Machinery: Enables fast communication for automated packaging and production equipment.
• Material Handling Equipment: Used in conveyor systems and automated transport applications requiring distributed control.
• OEM Machine Building: Suitable for industrial equipment requiring high-speed Ethernet communication architecture.
Advantages
• Dual Gigabit Ethernet Ports: Supports high-speed industrial communication and flexible network layouts.
• Compact 5000 Compatibility: Fully integrated with Allen Bradley CompactLogix systems.
• Reliable EtherNet/IP Connectivity: Ensures stable communication in demanding industrial environments.
• Compact DIN Rail Design: Saves panel space and simplifies installation.
• Fast Data Transmission: 10/100/1000 Mbps support improves communication efficiency.
• Flexible Distributed Control: Ideal for scalable industrial automation architectures.
FAQ
- What is the purpose of this EtherNet/IP adapter?
It provides communication between CompactLogix controllers and Compact 5000 distributed I/O systems. - How many Ethernet ports are available on the module?
The module includes dual 1 Gigabit Ethernet ports. - What communication speeds are supported?
It supports 10 Mbps, 100 Mbps, and 1000 Mbps Ethernet communication. - What power supply does the adapter require?
The module operates using an 18–32 VDC power supply. - What systems is this module compatible with?
It is designed for Allen Bradley CompactLogix and Compact 5000 I/O architectures. - What applications commonly use this adapter?
It is widely used in manufacturing automation, packaging systems, distributed I/O, and material handling equipment. - What is the benefit of dual Ethernet ports?
Dual ports support flexible industrial network configurations and easier system integration. - How is the module mounted?
The adapter is designed for DIN rail mounting inside industrial control cabinets. - Is the module suitable for high-speed industrial communication?
Yes, the Gigabit Ethernet capability provides fast and reliable real-time data transfer. - Does this module support distributed automation systems?
Yes, it is specifically designed for distributed I/O and industrial Ethernet automation applications.
Related Models
| Model | Type | Communication | Ports | Features |
|---|---|---|---|---|
| 5069-AEN2TR | EtherNet/IP Adapter | EtherNet/IP | Dual 1GB | Compact 5000 |
| 5069-IB16 | Digital Input Module | Compact 5000 | — | 16 Channel |
| 5069-OB16 | Digital Output Module | Compact 5000 | — | DC Output |
| 5069-OW16 | Relay Output Module | Compact 5000 | — | Relay Output |
| 5069-IF8 | Analog Input Module | Compact 5000 | — | Precision Analog |
| 5069-L306ER | CompactLogix Controller | EtherNet/IP | Dual Port | Motion Ready |
Popular Models
| Model | Type | Communication | Ports | Features |
|---|---|---|---|---|
| 5069-AEN2TR | EtherNet/IP Adapter | EtherNet/IP | Dual 1GB | Distributed I/O |
| 5069-L306ER | CompactLogix Controller | EtherNet/IP | Dual Port | High Performance |
| 5069-IB16 | Digital Input Module | Compact 5000 | — | High Density |
| 5069-OB16 | Digital Output Module | Compact 5000 | — | Compact Design |
| 5069-OW16 | Relay Output Module | Compact 5000 | — | Relay Switching |
| 5069-IF8 | Analog Input Module | Compact 5000 | — | Precision Signal Input |
