The Allen Bradley 5094-RTB3T Flex 5000 CJC Removable Terminal Block is a specialized terminal block designed for use within the Flex 5000 I/O platform. It provides a secure and reliable wiring interface for analog input modules while incorporating Cold Junction Compensation (CJC) functionality, which is essential for accurate thermocouple signal measurement in industrial automation applications.
The 5094-RTB3T is engineered to simplify field wiring, installation, maintenance, and module replacement procedures. Its removable design allows technicians to disconnect field wiring from the I/O module without disturbing existing wiring configurations, reducing maintenance time and minimizing the risk of wiring errors during system upgrades or module replacement activities.
A key feature of this terminal block is its integrated Cold Junction Compensation capability. In thermocouple measurement systems, accurate temperature readings depend on proper compensation for connection point temperature variations. The integrated CJC functionality helps improve measurement accuracy by compensating for ambient temperature changes at the terminal connection points, ensuring reliable temperature monitoring throughout industrial processes.
The terminal block utilizes screw-type connections that provide secure conductor retention and dependable electrical contact. This design is particularly suitable for industrial environments where vibration, electrical noise, and continuous operation are common. The 5094-RTB3T is widely used in process industries such as oil and gas, power generation, chemical processing, pharmaceutical manufacturing, food and beverage production, water treatment, and general industrial automation systems where precise temperature measurement is critical.
Product Specifications
| Parameter | Description |
|---|---|
| Model | Allen Bradley 5094-RTB3T |
| Product Type | Flex 5000 CJC Removable Terminal Block |
| Series | Flex 5000 I/O |
| Terminal Type | Removable Terminal Block |
| Compensation Function | Cold Junction Compensation (CJC) |
| Connection Method | Screw Terminal |
| Mounting Style | Screw Mountable |
| Application | Thermocouple Signal Wiring |
| Field Wiring Interface | Removable Design |
| Compatible Platform | Flex 5000 I/O System |
| Signal Support | Temperature Measurement Applications |
| Mechanical Construction | Industrial-Grade Housing |
| Maintenance Feature | Quick Removal and Replacement |
| Industrial Suitability | Process Automation Applications |
| Dimensions | 94 × 53 × 76 mm |
| Weight | 0.202 kg |
