Allen Bradley 1769-OW16 CompactLogix 16 Point AC/DC Relay Output Module
- Product Details
- FAQs
- Related
- Contact Us
- Packing & Delivery
- Product Ratings
Product Introduction
The Allen Bradley 1769-OW16 CompactLogix 16 Point AC/DC Relay Output Module is a versatile discrete output module designed for CompactLogix systems, providing reliable switching control for a wide range of AC and DC loads. Utilizing relay-based outputs, it offers excellent electrical isolation and flexibility when interfacing with different types of field devices.
With 16 output channels, this module is ideal for controlling devices such as contactors, solenoids, motors, and indicator lamps. Its ability to handle both AC and DC voltage ranges makes it suitable for mixed-load environments commonly found in industrial automation systems.
The robust relay design ensures dependable operation in demanding conditions, while its compact size allows efficient use of control panel space.
Product Specifications
| Parameter | Description |
|---|---|
| Model | 1769-OW16 |
| Product Series | CompactLogix |
| Module Type | Relay Output Module |
| Number of Outputs | 16 points |
| Output Type | AC/DC relay outputs |
| Output Voltage (AC) | 5–265 VAC |
| Output Voltage (DC) | 5–125 VDC |
| Current Rating | 20 A (total module capacity) |
| Isolation Type | Relay isolation |
| Signal Type | Discrete digital output |
| Mounting Type | DIN rail |
| Operating Temperature | 0°C to 60°C |
| Dimensions | 118 × 52.5 × 87 mm |
| Weight | 0.45 kg |
Applications
● Industrial control systems requiring switching of AC and DC loads across multiple output channels
● Manufacturing automation lines controlling contactors, solenoids, and indicator devices
● Machine control panels where relay outputs provide flexible load compatibility
● Process automation systems requiring reliable ON/OFF control of field equipment
● Mixed-voltage environments where both AC and DC outputs are needed within the same module
Advantages
● Supports both AC and DC outputs providing high flexibility for various industrial applications
● Relay-based isolation ensures safe and reliable switching of field devices
● 16-point output density reduces module count and optimizes panel space
● Wide voltage range compatibility allows connection to diverse load types
● Robust industrial design ensures long-term reliability in demanding environments
● Compact DIN rail mounting simplifies installation and maintenance
● Stable switching performance supports consistent control of industrial processes
FAQ
- What is the advantage of relay outputs compared to transistor outputs?
Relay outputs provide electrical isolation and can handle both AC and DC loads, making them more versatile. - What types of devices can this module control?
It can control contactors, relays, solenoids, motors, and indicator lamps. - Can this module switch high-voltage loads?
Yes, it supports a wide voltage range up to 265 VAC and 125 VDC. - Is it suitable for mixed AC and DC applications?
Yes, the relay outputs allow both AC and DC loads to be controlled within the same module. - What is the significance of the current rating?
It defines the total load capacity the module can handle safely. - Does the module provide electrical isolation?
Yes, relay contacts inherently provide isolation between control and load circuits. - Is this module suitable for frequent switching applications?
It can be used for switching applications, but relay life should be considered in high-frequency switching scenarios. - How is the module installed?
It is mounted on a DIN rail within a CompactLogix system. - Can it be used in harsh industrial environments?
Yes, it is designed for reliable operation in industrial conditions. - What systems typically use this module?
It is widely used in manufacturing, process control, and machine automation systems.
Related Models
| Model | Description |
|---|---|
| 1769-OW8 | 8-point relay output module |
| 1769-OB16 | 16-point transistor output module |
| 1769-OB32 | 32-point transistor output module |
| 1769-IA8I | 8-point isolated AC input module |
| 1769-IQ32 | 32-point DC input module |
| 1769-OF4 | Analog output module |
Popular Models
| Model | Description |
|---|---|
| 1769-L33ER | CompactLogix Ethernet controller |
| 1756-L71 | ControlLogix processor |
| 1756-IB16 | Digital input module |
| 1756-OB16E | Digital output module |
| 1763-L16BWA | MicroLogix 1100 controller |
| 1766-L32AWAA | MicroLogix 1400 controller |
