Schneider ATV320U22M2C Variable Speed Drive
- Product Details
- FAQs
- Related
- Contact Us
- Packing & Delivery
- Product Ratings
Product Introduction
The Schneider ATV320U22M2C Variable Speed Drive is part of the Altivar Machine ATV320 series, designed for precise and efficient control of three-phase synchronous and asynchronous motors in compact industrial machine applications. It provides stable motor speed and torque regulation while improving energy efficiency and reducing mechanical stress on equipment.
This model is rated for motor power up to 2.2 kW (3 hp) and operates on a 200V–240V AC three-phase supply. Its compact design allows vertical stacking inside machine frames, making it well-suited for OEM machinery where space optimization is critical.
The ATV320U22M2C is engineered for harsh industrial environments, featuring coated printed circuit boards compliant with IEC 60721-3-3 class 3C3. This design enhances resistance to dust, humidity, and corrosive conditions, enabling reliable operation at ambient temperatures up to 60°C without additional cooling in many installations.
It provides advanced motor control functions including sensorless flux vector control, strong torque performance at low speeds, and extended frequency capability for high-speed motors. It also supports energy-efficient operation for open-loop synchronous motors and allows parallel motor control in specific configurations.
The drive includes five integrated safety functions configurable via SoMove software, helping machine builders meet modern safety requirements and simplify system compliance.
The ATV320 series is widely used in OEM applications such as packaging systems, conveyors, textile machinery, material handling systems, and general industrial automation equipment.
Product Specifications
| Parameter | Description |
|---|---|
| Model | Schneider ATV320U22M2C |
| Product Type | Variable Speed Drive |
| Series | Altivar Machine ATV320 |
| Motor Type | Three-phase synchronous / asynchronous motor |
| Rated Power | 2.2 kW / 3 hp |
| Rated Voltage | 200–240 V AC |
| Control Method | Sensorless flux vector control |
| Frequency Range | Extended frequency operation |
| Cooling Requirement | Natural / optimized thermal design |
| PCB Protection Class | IEC 60721-3-3 Class 3C3 coated boards |
| Safety Functions | 5 integrated safety functions |
| Configuration Tool | SoMove software |
| Motor Control Features | Torque control, low-speed accuracy |
| Parallel Motor Operation | Supported (application dependent) |
| Energy Saving Function | Open-loop synchronous motor optimization |
| Protection Rating | IP20 |
| Standards | IEC/EN 61800-5-1, IEC/EN 61800-3 |
| Certifications | CE, UL, CSA, NOM, EAC, RCM |
| Dimensions | 158 × 105 × 142 mm |
| Weight | 1.6 kg |
Applications
• Packaging Machinery – Ensures stable speed control for sealing, labeling, and filling equipment.
• Conveyor Systems – Provides reliable material transport control in production lines.
• Textile Equipment – Supports controlled motion in spinning, weaving, and fabric processing machines.
• Material Handling Systems – Used in lifting, transfer, and automated logistics systems.
• Small Industrial Pumps and Fans – Improves energy efficiency and operational stability.
• OEM Machine Manufacturing – Ideal for compact machine designs requiring integrated motor control.
• Mechanical Actuators – Enables precise motion control in automated mechanical systems.
• Light Manufacturing Equipment – Suitable for general-purpose industrial automation tasks.
• Food Processing Machines – Supports controlled and hygienic production processes.
• General Industrial Automation – Used across a wide range of compact motor control applications.
Advantages
• Compact OEM-Oriented Design – Optimized for vertical stacking in machine cabinets.
• High Torque at Low Speed – Ensures stable operation in demanding load conditions.
• Sensorless Vector Control – Delivers precise motor performance without feedback devices.
• Improved Environmental Resistance – Coated PCB design enhances durability in harsh environments.
• Energy Efficiency Functions – Reduces power consumption in suitable operating conditions.
• Flexible Motor Compatibility – Supports both synchronous and asynchronous motors.
• Integrated Safety Functions – Helps meet machine safety requirements.
• Easy Commissioning via SoMove – Simplifies setup and parameter configuration.
• Reliable Thermal Performance – Operates up to 60°C in many applications without extra cooling.
• Wide Industrial Applicability – Suitable for diverse OEM machine applications.
FAQ
- What is the main purpose of the ATV320U22M2C variable speed drive?
It is used to control motor speed and torque in industrial machines, allowing smoother operation, better process control, and reduced mechanical stress on equipment during operation. - What type of motors can this drive control?
It can control both three-phase synchronous and asynchronous motors, making it suitable for a wide range of industrial and OEM machine applications. - What is the rated power of this model?
The ATV320U22M2C supports motors up to 2.2 kW (3 hp), which is typical for small to medium-sized machine applications requiring precise control. - Can this drive be used in harsh industrial environments?
Yes, it is designed with coated printed circuit boards that improve resistance to dust, humidity, and corrosive conditions, allowing reliable operation in challenging environments. - What control method does it use for motor operation?
It uses sensorless flux vector control, which provides accurate torque and speed regulation without requiring an external feedback encoder. - What industries commonly use this drive?
It is widely used in packaging, textile, conveyors, material handling, food processing, and general OEM machinery where compact and reliable motor control is required. - Does the ATV320U22M2C include safety functions?
Yes, it includes five integrated safety functions that can be configured using SoMove software to help meet modern machine safety standards. - Is this drive suitable for space-limited installations?
Yes, its compact design allows vertical stacking, making it ideal for machines where cabinet space is limited. - Can it improve energy efficiency in machines?
Yes, it includes energy-saving functions that optimize motor performance, especially in light-load or open-loop synchronous motor applications. - What is the advantage of using SoMove software with this drive?
SoMove simplifies configuration, parameter setting, and diagnostics, reducing commissioning time and making installation more efficient for machine builders.
Related Models
| Model | Description |
|---|---|
| ATV320U11M2C | Lower power single-phase compact drive |
| ATV320U07M2C | Small OEM variable speed drive |
| ATV320U30M2C | Higher power compact drive |
| ATV320D22N4 | Three-phase Altivar 320 drive variant |
| ATV320D15N4 | Mid-range three-phase version |
| ATV320U22N4B | Enhanced communication variant |
Popular Models
| Model | Description |
|---|---|
| ATV320U22M2C | Altivar Machine compact VSD (this model family) |
| ATV630D22N4 | Process automation variable speed drive |
| ATV930D30N4 | High-performance industrial drive |
| ATS480C21Y | Altivar ATS480 Soft Starter |
| BMENOC0301 | Ethernet communication module |
| BMEP584040 | Modicon M580 processor module |
