Schneider TM258LF42DT4L Logic controller
- Product Details
- FAQs
- Related
- Contact Us
- Packing & Delivery
- Product Ratings
Product Introduction
The Schneider Modicon M258 Logic Controller (Model: TM258LF42DT4L) is a high-performance programmable logic controller designed for advanced machine automation applications. As part of the Modicon M258 series, it targets machine builders requiring fast processing, flexible communication, and integrated control capabilities within a compact architecture.
This controller integrates a powerful CPU with a processing speed of 22 ns per instruction, enabling precise and high-speed control for complex automation tasks. It combines logic control, motion coordination, and communication functions into a single platform, reducing system complexity and improving overall efficiency.
Equipped with multiple communication interfaces, including Ethernet, CANopen, serial communication, and USB ports, the controller supports seamless integration into modern industrial networks. Built-in features such as data logging, WebServer, and FTP server capabilities further enhance system diagnostics, remote access, and data management.
Product Specifications
| Parameter | Value |
|---|---|
| Product Type | Logic Controller (PLC) |
| Series | Modicon M258 |
| Model Number | TM258LF42DT4L |
| CPU Performance | 22 ns per instruction |
| Digital I/O | 42 logic I/O |
| Discrete Input Type | Sink (fast & regular), Source (logic inputs) |
| Discrete Output Type | Source |
| Analog Input Type | Current: 0–20 mA / 4–20 mA; Voltage: ±10 V |
| Communication Ports | 5 ports total |
| Serial Communication | 1 × RS232/RS485 |
| USB Ports | 1 × USB mini-B (programming), 1 × USB Type-A (program transfer) |
| Ethernet Port | 1 × Ethernet |
| CANopen Port | 1 × CANopen master |
| Expansion Slots | 2 × PCI slots |
| Memory (Flash) | 128 MB |
| Memory (RAM) | 64 MB |
| Isolation | 500 Vrms between channels and internal logic |
| Channel Isolation | No isolation between channels |
| Built-in Functions | Data logging, WebServer, FTP server |
| Power Supply | 24 V DC |
| Mounting Type | Modular system with removable terminal blocks |
| Display | Integrated I/O status display |
| Dimensions | 237.5 x 99 x 85 mm |
| Weight | 0.77 kg |
Applications
• High-performance machine automation
Suitable for complex machinery requiring fast logic processing and precise control.
• Packaging and assembly systems
Enables synchronized operation of multi-axis machines and automated production lines.
• Material handling systems
Provides reliable control for conveyors, sorting systems, and robotic interfaces.
• Industrial process control
Integrates logic, communication, and monitoring for efficient process automation.
• Networked automation systems
Supports seamless integration with Ethernet and CANopen industrial networks.
Advantages
• High-speed CPU performance
Ensures rapid execution of control logic for time-critical automation tasks.
• Integrated communication capabilities
Multiple ports enable flexible connectivity with various industrial devices.
• Advanced built-in features
Data logging, WebServer, and FTP server enhance diagnostics and remote monitoring.
• Flexible I/O configuration
Supports multiple input/output types for diverse application requirements.
• Compact and modular design
Simplifies installation while allowing system scalability and expansion.
• Reliable industrial operation
Designed for stable performance in demanding industrial environments.
FAQ
- What makes the M258 controller suitable for high-performance applications?
Its fast CPU processing speed and integrated communication features allow it to handle complex control tasks efficiently. - What communication protocols does this controller support?
It supports Ethernet, CANopen, RS232/RS485 serial communication, and USB interfaces. - Can it be used for motion control applications?
Yes, it is designed for machine automation and can coordinate motion control through networked devices. - What built-in features improve system monitoring?
It includes data logging, a WebServer for remote access, and an FTP server for data transfer. - How flexible are the input and output configurations?
It supports sink and source inputs as well as multiple analog input types, making it adaptable to various applications. - Is external memory expansion required?
It includes built-in flash and RAM memory, but expansion can be achieved through system configuration if needed. - What is the purpose of the CANopen port?
It allows communication with CANopen-compatible devices such as drives and sensors. - How does the WebServer function help users?
It enables remote monitoring and diagnostics through a web interface. - What are common installation challenges?
Incorrect wiring, improper configuration of communication ports, and network setup issues are typical challenges. - Is it suitable for distributed automation systems?
Yes, its communication capabilities make it ideal for networked and distributed control architectures.
Related Models
| Model | Description |
|---|---|
| TM258LF24DT | Lower I/O count variant |
| TM258LF42DT | Standard configuration model |
| TM258LF66DT4L | Extended I/O version |
| TM258LF24DT4L | Compact version with communication |
| TM258LF42DT4 | Variant without extended features |
| TM258LF66DT | High I/O capacity model |
Popular Models
| Model | Description |
|---|---|
| M241 Logic Controller | Compact machine controller |
| M251 Logic Controller | Advanced motion controller |
| M262 Logic Controller | IIoT-enabled controller |
| BMXP342020 | Modicon M340 processor |
| BMXAMO0410 | Analog output module |
| BMXDDI1602 | Digital input module |
