Schneider TSXDSZ08T2K Relay Discrete Output Module

Product Introduction

---

The Schneider TSXDSZ08T2K is a high-performance digital output module designed for use within the Modicon Premium programmable logic controller (PLC) platform. As a part of Schneider Electric’s advanced automation solutions, this model delivers reliable control over discrete outputs in industrial environments. The TSXDSZ08T2K features transistor outputs and is tailored for fast-switching applications where performance and reliability are essential.

With a compact form factor and DIN rail mounting support, the module integrates seamlessly into control cabinets and automated systems. The 8-channel design offers precise digital signal control, making it suitable for controlling solenoids, indicators, relays, and small actuators in a wide variety of automation processes.

---

Product Features and Advantages

---

• High-Speed Switching: Transistor outputs support rapid switching for time-sensitive control.

• Compact and Modular: Fits within the Modicon Premium PLC rack, conserving panel space.

• LED Status Indicators: Each output channel includes LED indication for simplified diagnostics.

• Reliable Build Quality: Engineered by Schneider Electric to meet industrial-grade standards for reliability and longevity.

• Overload and Short-Circuit Protection: Protects the module and connected devices from electrical faults.

• Screw Terminal Block: Easy wiring and secure connection ensure robust installation.

• High Density: 8 outputs in one module reduce I/O expansion requirements.

---

Technical Specifications

---

---

Applications

---

The TSXDSZ08T2K is commonly used in:

• Manufacturing Automation: Controls actuators, conveyors, and robotic arms.

• Material Handling Systems: Provides output signals for sorting, labeling, and packaging machinery.

• Energy Management: Controls load-shedding relays and lighting systems.

• Process Control: Operates valves, pumps, and alarms in chemical and water treatment facilities.

• Building Automation: Integrates with HVAC systems and building safety controls.

• Transportation and Logistics: Supports automation in warehouse management and vehicle diagnostics.

---

Frequently Asked Questions (FAQs)

---

1. What type of output does the TSXDSZ08T2K provide?
   It provides 24V DC transistor (sink-type) digital outputs.

2. How many outputs are available on the module?
   The module features 8 independent digital output channels.

3. Is this module compatible with the Modicon M340 series?
   No, the TSXDSZ08T2K is specifically designed for the Modicon Premium series.

4. Can I use this module for high-speed pulse output?
   It is suitable for fast switching but not designed for high-frequency pulse output like PWM.

5. Does the module have overload protection?
   Yes, it includes integrated short-circuit and overload protection per channel.

6. What is the typical power consumption of this module?
   Power consumption varies by load but remains minimal due to efficient transistor output design.

7. Are replacement terminal blocks available separately?
   Yes, Schneider Electric provides spare parts including terminal blocks.

8. What indicators are available for troubleshooting?
   Each output channel has a dedicated LED indicator to show active state.

9. Is any additional software required for configuration?
   It is configured using Unity Pro or EcoStruxure Control Expert, Schneider’s PLC programming software.

10. Can the TSXDSZ08T2K be hot-swapped?
    No, it must be powered down before installation or removal to prevent damage or unsafe operation.

---
